2025 KTM 250 SX
Think "unbridled 2-stroke performance" and you'll probably see a KTM 250 SX in your mind's eye. For good reason too - there isn't much to compare it to. The 2025 KTM 250 SX takes that even further with a slew of fresh chassis enhancements, making it even more of a legend and one deserving of the record books.
This motorcycle is designed, developed and produced in Austria.
Engine
-
Transmission
5-speed
-
Starter
Electric starter
-
Stroke
72 mm
-
Bore
66.4 mm
-
Clutch
Wet, DDS multi-disc clutch, Brembo hydraulics
-
Displacement
249 cm³
-
EMS
Vitesco Technologies EMS
-
Design
1-cylinder, 2-stroke engine
-
Fuel-mixture generation
Keihin EFI, throttle body 39 mm
Chassis
-
Weight (without fuel)
99.4 kg
-
Tank capacity (approx.)
7.2 l
-
Wheelbase
1493 mm
-
Front brake disc diameter
260 mm
-
Rear brake disc diameter
220 mm
-
Front brake
Disc brake
-
Rear brake
Disc brake
-
Chain
520, Non-sealed
-
Frame design
Central double-cradle-type 25CrMo4 steel
-
Front suspension
WP XACT-USD (AER), Ø 48 mm
-
Ground clearance
354 mm
-
Handlebar
Neken, aluminium Ø 28/22 mm
-
Rear suspension
WP XACT Monoshock with linkage
-
Seat height
958 mm
-
Silencer
Aluminium
-
Steering head angle
63.9 °
-
Rear subframe design
Aluminum-reinforced polyamide
-
Suspension travel (front)
310 mm
-
Suspension travel (rear)
300 mm
-
Wheels
Spoked wheels with aluminium rims
